Rigid Wall II™ Series is a structural wall panel that is offered in 18 design options. Available in widths of 16”, 12” and 8”, these structural panels can be installed vertically or horizontally with concealed fasteners. This mix-and-match family of panels can be combined in various patterns to create distinctive, eye-catching facades. The Wind-Lok® interlock allows the Rigid Wall II™ Series panels to be combined with Corra-Lok™, Metafor™, and Multi-Purpose™ for the ability to create interesting patterns and breaks.
- Available in a variety of widths and profiles 8”, 12”, and 16” wide
- Structural panelsCan be installed vertically or horizontally with concealed fasteners
- Can be applied to open framing
- Features our trademarked Wind-Lok® system for added versatility
- Mix and match capabilities
- Integrates with our Elite Trims
- Minimum panel length: 2’-8”
- Material.032, .040, .050 aluminum
- 24, 22*, 20*, 18* ga. metallic coated steel
- 24, 22*, 20*, 18* ga. 55% Al-Zn alloy coated steel with acrylic coating
- 1.0 mm zinc*
- TextureSmooth
- Stucco Embossed
- Perforations available
- Choice of over 40 stock colors
- Custom colors and finishes available
- Clear Satin & Dark Bronze Anodized
*SUBJECT TO MINIMUM QUANTITIES AND EXTENDED LEAD TIME INQUIRE FOR MATERIAL AND PANEL COVERAGE AVAILABILITY
