ScanRoof
ScanRoof™, a scalloped tile with a Northern European flair, is an easy-to-install metal roof panel. The panels are structural, practical and unique, making it ideal for steep slope roof projects. ScanRoof™ is the ideal roof system to stand up against Mother Nature’s storms, typhoons, hurricanes, damaging winds and driving rains. The panel is installed horizontally, from eave to ridge. ScanRoof™ has a 2” high integral Z purlin allowing for air flow between the panel and substrate. It is lightweight, allowing installation over an existing roof without the need for tear-off and disposal*. Typical applications for ScanRoof™ are commercial and residential roofing with a recommended minimum slope of 3:12. It also is suitable for mansards.
Florida Building Product Approval: FL 3162.1
*Subject to local building codes

SCP163
24 ga. metallic coated steel
16½” x 13′-2″
Smooth
70% PVDF
Choice of 35 stock colors
Premium colors are not recommended
Custom colors available*
A complete line of trims available in matching colors, gauge, and finish or as specified
3:12
FL 3162.1
Premium Painted
Details provided allow for typical expansion and contraction values of the metal cladding materials as provided by ATAS International, Inc only. Allowance must be made for additional sub-structure movement based upon materials used and overall project design.
PDF File Format
- ScanRoof - All Details
- ScanRoof - Fastening Pattern Detail
- ScanRoof - Eave Detail
- ScanRoof - Gable Detail
- ScanRoof - Sidewall Detail
- ScanRoof - Hip Detail
- ScanRoof - Valley Detail
- ScanRoof - Ending On Purlin Detail
- ScanRoof - Headwall Detail
- ScanRoof - Vented Headwall Detail
- ScanRoof - Ridge Detail
- ScanRoof - Vented Ridge Detail
- ScanRoof - Shed Ridge Detail
- ScanRoof - Vented Shed Ridge Detail
DWG File Format
- ScanRoof - Fastening Pattern Detail
- ScanRoof - Eave Detail
- ScanRoof - Sidewall Detail
- ScanRoof - Hip Detail
- ScanRoof - Gable Detail
- ScanRoof - Valley Detail
- ScanRoof - Ending On Purlin Detail
- ScanRoof - Headwall Detail
- ScanRoof - Vented Headwall Detail
- ScanRoof - Ridge Detail
- ScanRoof - Vented Ridge Detail
- ScanRoof - Shed Ridge Detail
- ScanRoof - Vented Shed Ridge Detail
