Linear Ceiling Series

Linear Ceiling Series

Profile Options:

LCR - Recessed Overview
LCR - Recessed Overview
LCR - Recessed Close-Up
LCR - Recessed Close-Up
LCR - Flush Overview
LCR - Flush Overview
LCR - Flush Close-Up
LCR - Flush Close-Up
LCB - Recessed Overview
LCB - Recessed Overview
LCB - Recessed Close-Up
LCB - Recessed Close-Up

Linear Ceiling™ is a system comprised of a suspended or positive fastened carriers with metal panels snapped into place within the carrier.  The Linear Ceiling™ system is available in two distinct profiles: round edge (LCR) or a square box (LCB) with or without filler strips. Each profile has a choice of two widths that are interchangeable due to the 4” increments of the carrier system. The two ceiling widths provide coverages of 4” and 8”. Panels are available in varied widths of 4”, 8” and 12” wide modules.  The use of filler strips provide either a flush or revealed appearance.  Filler strips can be removed to provide ventilation within the system or panel can be perforated or louvered if desired.

Round Edge SKU:

LCR338
LCR738

Box Style SKU:

LCB338
LCB738

Material:

.019, .024, .032 aluminum

Panel Coverage:

3 3⁄8″
7 3⁄8″

Minimum Panel Length:

4’-0”

Maximum Panel Length:

45’-0”

Panel Height:

5⁄8″

Texture:

Smooth
Perforated
Lanced

Finish:

70% PVDF
Polyester
Mirrored
Laminates

Color:

Choice of over 30 stock colors in .032 aluminum
.019 and .024 aluminum available in Bone White
Custom colors available*

Anodized:

Clear Satin
Dark Bronze

Accessories:

Suspended carrier
A complete line of trims available

Carrier:

Metal: Aluminum
Gauge: .040
Length: Standard 12’

Filler Strips (optional):

Available in .019 in Black or Bone White
