Multi-Purpose™ Panels

The Multi-Purpose™ panels with the Wind-Lok® interlock have a smooth but sleek appearance with a concealed clipless fastening system. This interlock also allows the Multi-Purpose™ panels to be combined with Corra-Lok™, Metafor™, and Rigid Wall II™ for the ability to create interesting patterns and breaks. Typical applications include walls, fascias, mansards, equipment screens and some limited roofing with a minimum slope of 3:12.

You can also enhance aesthetics of Multi-Purpose™ by using factory fabricated Elite Series accessories, including the Z Box and Closure Angle.

SKU:

• MPN, MPW, MPV, MPH, MPS

Material:

• .032, .040 aluminum
• 24, 22* ga. metallic coated steel
• 16, 20 oz. copper*
• .8, 1.0 mm zinc*
• .0197 classic & tin matte stainless steel*
• (MPS: .032 aluminum)

Panel Coverage:

• 8″, 12″ and 16″

Panel Depth:

• 1¼”
• ⅜” (MPS)

Minimum Length:

• 3’-0”

Texture:

• Smooth
• Stucco Embossed
• Wood Grain Embossed (24 ga. metallic coated steel, .032 aluminum & .040 aluminum only)

Perforations Available: yes

Colors:

• Choice of over 40 stock colors
• Custom colors and finishes available*

*Subject to minimum quantities and extended lead time. Inquire for material and panel coverage availability
